Photometric
and Performance Data
|
SERIES 407
(2-light) Up Light
|
|
|
92%
|
Total Luminaire Efficiency
|
|
Zonal Lumen Summary
Zone Lumens %Lamps
%Fixture
0-30
1227 21
23 0-40 2050
35 38 0-60
3810 66
71 0-90 4939
85 92 90-120
55
1 1 90-130
99
2 2 90-150
267
5 5 90-180
424
7
8 0-180 5363
92 100
|
|
|
|
COEFFICIENTS OF UTILIZATION (CU) - ZONAL CAVITY METHOD
RF
20
RC 80
70
50
30
10
0
RW 70 50 30
10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
|
|
0 110 110 110 110 106 106 106
106 100 100 100 94 94 94
89 89 89 86 1 100 95 91
88 96 92 89 85 87
84 81 82 80 78 78
76 74 71 2 90 83 76
71 87 80 74 69 76
71 66 71 67 64 68
64 61 59 3 82 72 64
58 79 70 63 57 66
60 55 63 57 53 59
55 51 49 4 75 64 55
49 72 62 54 48 58
52 47 55 50 45 53
48 44 41 5 69 56 48
42 66 55 47 41 52
45 40 49 44 39 47
42 38 36 6 63 51 42
36 61 49 41 36 47
40 35 45 38 34 42
37 33 31 7 59 46 37
32 56 45 37 31 42
36 31 40 34 30 39
33 29 27 8 54 42 34
28 52 41 33 28 39
32 27 37 31 27 35
30 26 24 9 51 38 30
25 49 37 30 25 36
29 24 34 28 24 33
27 23 21 10 47 35 28 23 46 34
27 22 33
26 22 31 26 21 30
25 21 19
|
|
